PVD Thermal Evaporation Equipment , High Capacity and Fast Deposition Vacuum Metalizing Equipment

1 set
MOQ
negotiable
Price
PVD Thermal Evaporation Equipment , High Capacity and Fast Deposition Vacuum Metalizing Equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Chamber: Vertical Orientation, 1-door
Technique: Thermal Evaporation Technique Thin Film Deposition
Evaporation Source: Thermal Filament, Thermal Boat, Thermal Box, Rod, Crucibles
Deposition Materials: Aluminum, Gold, Silver, Chromium, Copper, Indium, Indium Tin Oxide, Nickel
Applications: Furnitures, Dashboards, Knobs, Buttons, Plates, Fashion And Costume Jewelry Accessories, Toy Parts, Lifestyle Products, Car Lighting, Christmas Decorations
Chamber Inner Size: Dia2200 * H 1500mm
Factory Location: Shanghai City, China
Worldwide Service: Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Worldwide Service: Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Worldwide Service: Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Training Service: Machine Operation, Maintenance, Coating Process Recipes, Program
Warranty: Limited Warranty 1 Year For Free, Whole Life For Machine
OEM & ODM: Available, We Support Tailor Made Design And Fabrication
OEM & ODM: Available, We Support Tailor Made Design And Fabrication
High Light:

thermal evaporation unit

,

vacuum deposition machine

Basic Infomation
Place of Origin: Made in China
Brand Name: ROYAL
Certification: CE certification
Model Number: RTEP2200
Payment & Shipping Terms
Packaging Details: Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Delivery Time: 8~12 weeks
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 10 sets per month
Product Description

                          PVD Thermal Evaporation Coating Machine, Vacuum Metalizing Equipment



PVD (Physical Vapor Deposition) thermal evaporation process is 100% environmentally friendly. As an advanced coating technology to replace the traditional electroplating, its high quality finishing, fast deposition rate, brilliant uniformity, strong adhesion and low production cost properties becoming it an ideal solution for various industries:
A: Decorative Coatings: ABS, PP, PC, PET, PMMA to deposit a thin film, high reflective, metallic like coating on toys, fashion and consume jewelry accessories, Christmas tree decorations, balls, buttons, shoes, mirrors, lamps.
B: Functional Coatings: protective layer: ZrO2 coatings on blades for heat insulation, HMDSO molymerization protective layers by PECVD, EMI & NCVM on electronics.

C: Optics Coatings: Anti-Reflection coating (AF film), telescope, periscope, microscope and digital camera.




1. Standard Evaporation Machine Models


Model Size(mm) Substrate Jigs (Qty.) Evaporation Power(kVA) Plasma (kVA) Ultimate Vacuum Cycle Time Electrical Power
RTEP1012 Φ1000xH1200 6,8,10 20 7 8x10-4Pa 10'~15' depends on Product

3Phase/AC380V,50HZ
3Ph, 220 to 440V,60HZ

RTEP1416 Φ1400xH1600 6, 8,16 30 7
RTEP1418 Φ1400xH1800 6,16 35 10
RTEP1616 Φ1600xH1600 8.16 35 10
RTEP1618 Φ1600xH1800 8.16 35 10
RTEP1820 Φ1800xH2000 6 40 10
RTEP2022 Φ2000xH2200 10,12,16 40 10


2. Customized Evaporation Machine Models


RTEP3618 Φ3600xH1800 1 80   8x10-4Pa 10'~15' depends on Product

3Phase/AC380V,50HZ
3Ph, 220 to440V,60HZ

RTEP2215 Φ2200xH1500 1 50 10
RTEP2525 Φ2500xH2500 3 50 20
RTEP6638 L6600xH3800 100 20
RTEP0913 Φ900xH1300
RTEP1822 Φ1800xH2200 6 50 10



3. PVD Evaporation Coating Machine Features
A: PLC + Touch Screen Operation System, fully automatically control
B: Fast Vacuum pumping down time.
C: Work pieces are easy loading/uploading.
D: Easy access to the working environment for maintenance.
E: Robust structure design and high quality configurations

4. Thermal Evaporation Machines Project
    Built Time: 2015
    Location: South Korea
    Industry: Automobile LOGO PMMA Chroming coating
PVD Thermal Evaporation Equipment , High Capacity and Fast Deposition Vacuum Metalizing Equipment 0

5. Car LOGO vacuum chroming products:


PVD Thermal Evaporation Equipment , High Capacity and Fast Deposition Vacuum Metalizing Equipment 1



PVD Thermal Evaporation Equipment , High Capacity and Fast Deposition Vacuum Metalizing Equipment 2



PVD Thermal Evaporation Equipment , High Capacity and Fast Deposition Vacuum Metalizing Equipment 3





Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
