2021 Newest developed coatings- brown color on automotive ABS articles
1 set
MOQ
negotiable
Price
2021 Newest developed coatings- brown color on automotive ABS articles
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: ROYAL
Certification: CE
Model Number: RTAC1600+
High Light:

thin film deposition equipment

,

dlc coating equipment

Payment & Shipping Terms
Packaging Details: Plywood
Delivery Time: 12 weeks
Payment Terms: L/C, T/T
Supply Ability: 5 sets per month
Specifications
Functional Coatings: Scratch Resistance, Corrosion Resistance, Thermal Shock Testing
Decorative Coatings: Brown, Rose Gold, Copper, ZrN Gold, TiN Gold, TiCN Black, TiO Blue, Green, Rainbow Etc.
PVD Finishing: PVD Mirror, PVD Matte Colors
Factory Location: Shanghai City, China
Factory Location: Shanghai City, China
Factory Location: Shanghai City, China
Factory Location: Shanghai City, China
Worldwide Service: Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Worldwide Service: Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Training Service: Machine Operation, Maintenance, Coating Process Recipes, Program
Warranty: Limited Warranty 1 Year For Free, Whole Life For Machine
OEM & ODM: Available, We Support Tailor Made Design And Fabrication
Product Description
The automotive industry uses PVD coating process for a variety of interior and exterior plastic trims.





Consumers always expecting a unique and tailored made color, Royal technology developed a new BROWN yellow color by ion plating as the request of car components manufacturer.



Royal  team can assist you to develop more tailored coatings which give a high extra value of your products.




How it benefits the automotive industry?

1. Environmentally friendly coating procedure

2. Decreased fuel consumption due to its light weight

3. Increased Durability and Chemical Resistance

4. Varieties of colors, thickness and uniformity can be controlled.



Summary: Chrome plating as a stable, excellent shiny decoration, corrosion prevention and abrasion wearing film surface treatment, in the last decades, it extensively be used for many industries. However, the hexavalent Chrome (Cr6+) electroplating damaged health of operators and ruined our environment. So, trivalent Chrome (Cr3+) was used to taken place of the (Cr6+) plating. With the higher requirement of quality and lower production cost demands by manufactures, now, an alternative solutions to replace expensive cost of (Cr3+) electroplating, the most important is without negative health impact and environmentally hazard effluence has been required.



When this subject come to PVD, it solved. Royal Technology has designed and developed the standardized PVD coating equipment used for various substrate materials:



ABS, ABS + PC, PA, Brass, Brass Alloy, Metal Steel, Zinc Alloy, Aluminum and Aluminum Alloy etc. With the PVD chrome processing, it changed the traditional process treatment in automotive industry, transportation vehicles, clocks, tooling instruments, hardware, bathroom and kitchen appliance and other many parts need protective layer and aesthetic coatings.





Features:



PVD Machine Model: RTAC1600+ equipped with multi-arc vacuum coating sources and DC sputtering cathodes, which available for all plastic and metal substrate products PVD chrome plating.



The PVD plating process is between base and top lacquer thermal heating painting process. We can get high quality of Chrome color, stainless steel color and gold colors.



Except the high finishing surface, abrasion wearing and anti-corrosion properties, the hardness also can achieve up to 4H.



Besides, Polycold device is for option especially for ABS parts processing.







Configurations:



MODEL RTAC1600+
TECHNOLOGY Arc evaporation + DC magnetron Sputtering + Plasma cleaning
MATERIAL Stainless Steel (S304)
CHAMBER SIZE φ1600*1600mm (H)
PUMP SYSTEM Rotary Vane Vacuum Pump (Mechanical)
Rotary Vane Vacuum Pump (Holding)
Roots Vacuum Pump
High Vacuum Oil Diffusion Pump
TECHNOLOGY Ion Plating ( Multi-arc sources) + DC sputtering + Ion Source (for option)
POWER SUPPLY Arc 9*5KW + DC Sputtering 2*48KW
TYPICAL TARGETS Titanium, Zirconium, Chrome, Silver, Au gold, Aluminum, Copper etc.
GAS Gas Mass Flow Meters ( Ar, N2, C2H2, O2) Argon, Nitrogen and Ethyne,Oxygen
CONTROL PLC(Programmable Logic Controller)
SAFETY SYSTEM Numerous safety interlocks to protect operators and equipment
COOLING Water
HEATING Heater
POWER MAX. 120KW (Approx.)
AVERAGE POWER CONSUMPTION 55 KW (Approx.)



Learn how our customer say about this total coating solutions:





21st. April 2018



To Royal Technology:



I bought the PVD-machineRTAC-1416. After the start-up and commissioning of the equipment, ceramics, glass and stainless steel were coated. The quality of the coating is excellent.
To cover Al-Zn alloys products, additional surface preparation of the parts to be coated is necessary. The best option is to pre-coat parts with nickel, and then topcoat the decorative coating. But since there are problems with galvanizing and nickel plating, you can do without it. The seller of this equipment can provide the technology of coating without the use of electroplating.
The colors are varied and very beautiful, especially on glass and ceramics. It makes no sense to spend money on expensive targets of chromium, instead of them you can use titanium targets, which are five times cheaper, and the resulting color is practically the same.
The company also provides services for the launch of equipment. At start-up, an interpreter is needed. We used the services of an interpreter who did not have a sufficient level of technical language knowledge. But, in principle, everything was clear, due to the very accessible and user-friendly interface of the software, and a convenient touch screen.
When buying a PVD-machine you need to have a compressor and a chiller. We were recommended to have a compressor at 9-10 atm., but quite enough 5-6 atm. Also the company provides the necessary spare parts.
Before buying a PVD-machine, all negotiations were conducted on the Internet. The end result: the PVD-machine is stands and works at my place.
I want to express special gratitude to the highly skilled manager of the company Miss Zhou Xin, who helped bring the matter to its logical completion.



TSykalo Sergey Alekseevich (Zaporozhye, Ukraine)
