RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine
1 set
MOQ
negotiable
Price
RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Made in China
Brand Name: ROYAL
Certification: CE
Model Number: RTSP1215
High Light:

vacuum coating plant

,

high vacuum coating machine

Payment & Shipping Terms
Packaging Details: Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Delivery Time: 14 weeks
Payment Terms: L/C, T/T
Supply Ability: 6 sets per month
Specifications
Coating Technology: Sputtering, Evaporation, Plasma Treater
Equipment Features: Robust Structure, Compact Footprint Design, High Efficiency And Precision Oepration Control
Coating Application: Electronic Paper, ITO Film, Flexible Circuits, Photovoltaic, Medical Strips And RFID.
Operation Control: Intuitive PLC And IPC Control
Service And Training: Available, From The USA Engineer And Technicians
Factory Location: Shanghai City, China
Factory Location: Shanghai City, China
Worldwide Service: Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America
Training Service: Machine Operation, Maintenance, Coating Process Recipes, Program
Warranty: Limited Warranty 1 Year For Free, Whole Life For Machine
OEM & ODM: Available, We Support Tailor Made Design And Fabrication
Product Description

Applications

The RTSP1215 machine is tailor-designed and made for cooper PCBs gold plating by sputtering deposition technology.

Everyone who are involved with the PCB industry knows that PCBs which have copper finishes on the surface requires a protective layer to protect it against from oxidize and deteriorate.

2 Years ago, we received a request from our customer, they were looking for a coating solution generate a fine gold and bronze colors on the copper PCBs which used for 5G SIM card, social security cards and smart cards module. We spent 6 months in R&D, over 20 times experiment to finalized the proper coating processes. In March 2020, we delivered the machine to customer’s site with a high accomplishment.

RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 0 RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 1



RTSP1215 plating system can deposit the metals: Au gold, Ag silver, Cu copper conductive families films; corrosion resistance metal families: Tantalum(Ta), Nickle (Ni), Chrome (Cr) etc.
compounded films: carbon-based metal films, Nitride metal films.

PVD Gold Plating Advantages

Environmentally friendly process

Much lower production cost compared with conventional Gold electroplating

Excellent Life

Film thickness and uniformity are well controlled

Widely available, more options for end user

Key Features

Multiple deposition sources for fast deposition rate

Strong vacuum pumping system for a short cycle

Anode linear ion source to improve adhesion and high density of deposited films

6 units standard planar cathodes mounting flanges

Flexible coating processes applied

Modular structure design for fast exchange of cathodes and targets

5G circuit microchip SIM card emblem isolated on white background

RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 2 RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 3
Technical Specifications
RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 4


Model: RTSP1215

Chamber Material: SUS304

Chamber Size: Φ1200*1500mm (H)

Deposition Technology: Magnetron sputtering

Targets: Ta, Au, Ag, Ti,Cr,Zr, Ni, Cu, Graphite (C) etc

Vacuum Pumps: Mechanical Pump: 1x300m³/hr

Holding Pump:1x60m³/hr

Roots Pump: 1x300L/S

Turbo Molecular pump: 2x3500L/S

Gas System: MFC for reactive gas and inert working gas

Protective System: HMI program with Multiple Self-Lock design

Operation & Control System: PLC + Touch Screen

Cooling System: Recycle Cooling water

Heating System: Heaters with PDI thermal couple

Max. Power Consumption 130KW Approx.

Average Power Consumption 70KW Approx.

Layout
RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 5 RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 6

Insite


Built Time: 2020

Location: Shanghai, China

RTSP1215-Printed Circuit Board (PCB) Gold Plating Equipment, TiN Gold Sputtering Machine 7


Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
