Cathodic Arc Coating Technology and Machines, PVD decoration coating by arc plating, Multi arc decorative coatings
Advantages
Many bright colors of final finishings
Excellent scratch resistance
Enables longer life of products
Environmentally-friendly process
Robust and high volume design machine
HMI friendly operation system
Low maintenance
Low cost of ownership
Applications
Bathroom and shower fixtures
Sanitary ware and plumbing applies
Door handles, fasteners, safe and locks
Glass and ceramic products
Eyewear
Writing Instruments
Only to name a few, but for more applications, please contact Royal Technology
FASTER, MORE STABLE, BRILLIANT FINISHING
1. Cathodic arc is an upgraded design to optimize emission of droplets
2. The Ion evaporator with an auto pneumatic driving ignition system, manual ignition button to control the target and efficiently improve the utilization
3. IGBT model of cathodic arc inverter power supply, arc discharge from 30A to 200A, arc current can be set and adjusted by PLC on the touch screen
4. Cathodic arc with direct cooling method, low temperature evaporation is available.
5. Stable process operation in a wide pressure range.
STANDARD, MODULAR DESIGN
1. PS eletrical enclosure, designed and manufactured strictly following CE standards
2. Central control cabinet with PLC, power output control and general power distributor
3. Operating software program in PLC is exclusive developed by Royal Technology, each set machine is ready for system upgrading
Royal Technology provides different sizes machines to satisfy customers demand, from S, M to L model, we believe
there is one model suitable for you.
| Description | RTAC1000 | RTAC1200 | RTAC1400 | RTAC1600 |
|
Standard Applications |
Medical & beauty instruments, pen, watches, glass beads, small size products | Door handles, safe and locks, eyewear, fasteners, consumer electronic metal parts | Sanitary ware, bathroom fixtures, glassware of medium size |
Faucets, plumbings, furniture components, metal lamps, for high volume products |
|
Deposition Chamber (mm) |
φ1000 * H800 |
φ1200 * H1500
|
φ1400 * H1600 |
φ1600 * H1800
|
|
Maximum Loading (kg) |
500 | 800 | 800 | 1000 |
|
Central Driving Effective Coating Area (mm) |
φ800*H500 |
6: φ760*H1100 8: φ700*H1100 |
6: φ835*H1200 8: φ905*H1200
|
8: φ900*H1500 10:φ1000*H1500 |
|
Planetary Driving Effective Coating Area (mm) |
6*φ250*H500 |
6: φ320*H1100 8: φ260*H1100 |
6: φ370*H1200 8: φ300*H1200 |
8: φ350*H1400 10: φ290*H1400
|
|
Pulsed Bias Power (KW) |
24 | 24 | 36 | 48 |
| Circular Arc Cathode (sets) | 6 | 14 | 14 | 18 |
| High Vacuum Pumps | 1*Turbo Molecular Pump | 2 * Turbo Molecular Pumps |
1* Diffusion Pump or 3* Turbo Molecular Pumps |
2* Diffusion Pumps or 4* Turbo Molecular Pumps |
| Backing Pumps | 1*SV300B + 1*WAU501+ 1*TRP36 |
2*SV300B+1*WAU1001 +1*TRP48 |
2*SV300B+1*WAU2001 +1*TRP60 |
1*SV630BF+1*WAU2001 +1*TRP90 |
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
