Bronze Color Magnetron Sputtering Coating Machine , Metal Thin Film Arc Ion Plating Machine
1 set
Bronze Color Magnetron Sputtering Coating Machine , Metal Thin Film Arc Ion Plating Machine
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: Made in China
Brand Name: ROYAL
Certification: CE certification
Model Number: RTAS1250
High Light:

silver plating machine


ion plating system

Payment & Shipping Terms
Packaging Details: Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Delivery Time: 6 to 12 weeks
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 15 sets per month
Chamber: Vertical Orientation, 1-door,
Vacuum Technology: Arc Evaporation, Arc Ion Plating + MF Sputtering
Deposition Sources: Arc Cathodes + Sputtering Cathodes
Coating Films: Metal Film Plating, Titanium Nitride, Titanium Carbide, Zirconium Nitride, Chromium Nitride, TiAlN, CrC
Industrial Applications: Ceramic And Glass House Wares, Stainless Steel Table Ware, Steel Sheet, Furniture, Table, Chair, Watches And Clocks, Hard Coatings On Tools
Product Description

Bronze color PVD vacuum Plating machine / Copper color ion plating coater / House ware PVD vacuum coating machine



RTAC-SP machine is for decorative coating on all kinds of house wares like: glass / metal / stainless steel materials.


Coating Equipment Features


1. High ionization rate , high deposition speed and strong adhesion
2. To replace the water-electroplating, 100% environmentally friendly.

3. Advanced control system and easy to operate , deposited at various substrate materials.




MATERIAL Stainless Steel (S304)
CHAMBER SIZE Φ1250*1250mm (H)
CHAMBER TYPE Cylinder, vertical, single door
SINGLE PUMP PACKAGE Rotary Piston Vacuum Pump
Roots Vacuum Pump
Turbo Molecular Pump
TECHNOLOGY Magnetron Sputtering + Ion Plating
POWER SUPPLY MF power supply + Bias Power supply + Arc Powers
DEPOSITION SOURCE 4 sets of Cylinder Sputtering Target + 8 sets of Cathodic Arc Sources
CONTROL PLC+Touch Screen
GAS Gas Mass Flow Meters
SAFETY SYSTEM Numerous safety interlocks to protect operators and equipment
COOLING Cooling Water
CLEANING Glow Discharge Cleaning



70 KW

Coating Films:


To coat metal film, titanium nitride, titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper, and other compounds films.




Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
