Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics
1 set
MOQ
negotiable
Price
Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Made in China
Brand Name: ROYAL
Certification: CE certification
Model Number: RTEP1616-SPDC
High Light:

thin film coating equipment

,

thin film deposition equipment

Payment & Shipping Terms
Packaging Details: Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Delivery Time: 12 weeks
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 10 sets per month
Specifications
Chamber: Vertical Orientation, 2-doors
Material: Stainless Steel 304/316
Evaporation Source: DC Sputtering, Thermal Filament, Thermal Boat, Thermal Box, Rod, Crucibles
Deposition Materials: Aluminum, Gold, Silver, Chromium, Copper, Indium, Indium Tin Oxide, Nickel
Applications: Plastic Table Ware, Helmet Visors, Electronics, Acrylic, Lamps, Mobile Viewing Window, Glasses, Lighting
Chamber Inner Size: Dia1600 * H1600mm
Product Description





Thin Films Deposition Vacuum Sputtering Systems , Thermal Evaporation Equipment







Thin Films Deposition Vacuum Sputtering + Thermal Evaporation System Applications:



ABS one-time using tableware, EMI shielding and NCVM films in electronic products; Decorative items, Metallic finishing, Chroming, Aluminum metalizing purpose on plastic parts, construction material, atrs&craft etc.
Coating Functions: Protective coating, functional coating, decoration coatings
Film: Metal film, semi-transparent film, Mobile phone EMI, NCVM, Dielectric film; with proper coating process/ coating recipes, it can achieve desired results for such variables as thickness, uniformity, adhesion strength, stress, grain structure, optical or electrical properties etc.







Thin Films Deposition Vacuum Sputtering + Thermal Evaporation System machine, the model: RTEP-SP series consist of vacuum coating chamber , vacuum pumping system, deposition system, cooling system , electrical control system , workpiece rotating rack. It is a duel function peice of equipment, the evaporation function is a high quality coating aluminum on the surface of plastic, while the magnetron sputtering function is mainly specialized for plating stainless steel on the product surface.



Thermal Evaporation and Sputtering Metalizing Machine Features:
Dual chambers for independent loading operations.
Four types of coating process modes available for selection.
Option: RF generators or magnetron sputtering source can be installed for surface coating.
Uses planetary rotation mechanism to achieve good film uniformity on curved surface substrates.





Thin Films Deposition Vacuum Sputtering  + Thermal Evaporation System machine Standard Models:



Model Size(mm) Substrate Jigs (Qty.) Evaporation Power(kVA Cathode (KW) Cycle Time

Electrical

Power

RTEP1212-SP 1200xH1200 6,8 20 DC30 10'~40' depends on Product 3Phase/AC380V,50HZ
RTEP1214-SP 1200xH1400 6, 8,16 20 AC36
RTEP1414-SP 1400xH1400 6,16 35 DC30
RTEP1416-SP 1400xH1600 8.16 35 DC35
RTEP1616-SP 1600xH1600 8.16 35 DC50
RTEP1618-SP 1600xH1800 8.16 35 DC50







Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 0







Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 1

Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 2

Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 3








Tungsten Filament Evaporation sources



Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 4



Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 5



Planar DC Sputtering Cathode Sources:



Vacuum Sputtering Thin Film Deposition Equipment , Thermal Evaporation Equipment For Electronics 6





Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
