Hard Coating Cathodic Arc Deposition System Thin Film With High Accuracy
1 set
Hard Coating Cathodic Arc Deposition System Thin Film With High Accuracy
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: Made in China
Brand Name: ROYAL
Certification: CE
Model Number: RT-HTC
High Light:

hard coating machine


pvd coating equipment

Payment & Shipping Terms
Packaging Details: Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.
Delivery Time: 12 weeks
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10 sets per month
Material: Stainless Steel 316L
Deposition Sources: Steered Cathodic Arc Sources
Technique: PVD, Arc Evaporation
Applications: Steel Precision Fasteners, Screws, Tools, Injection Molds
Film Features: Hard Coatings , Wear Resistance, Strong Adhesion
Product Description



Hard Film Ion Plating Machine / Hard Coatings PVD Ion Plating Equipment


Hard Film Ion Plating Machine Applications:


Hard coatings are becoming widely used in the decorative coating and industrial tools (HSS or HSC
materials). The coatings are more resistance to wear and corrosion, to fulfill the tools functions more reliably and for a longer life time, 2-3 times longer than without coating in general.
Cutting Tools: ( Suggested Coatings: AlTiN/TiAlN, TiCN and TiN)

Sawing, milling, CNC insert ( hard turning using), drilling, hobbing and gear cutter etc.
Punching & Forming ( Suggested Coatings: CrN, TiCN and TiN)
Metal Stamping
Moulding ( Plastic Injection Mold) -- ( Suggested Coatings: TiCN and TiN )
Die Casting
Precision Components
Others, like: machine tools, texitile machine, re-coating, re-sharpening applications etc.


Hard Film Ion Plating Machine  Description

1. RT-HAC equipment systems consists of: vacuum chamber, vacuum pumps, arc sources, spindle & jack, jigs structure, heating & cooling, water & gas( distribution), electrical control & operation systems etc.
2. Application: industrial functional coatings for hard tools.
3.Coating Films: TiN, TiC, CrN, AlTiN etc.
4.Coating Advantages: high hardness and wear-resistance and corrosion,increased tool life time & improved workpiece quality. "

Hard Film Ion Plating Machine Technical Advantages
1. Strong background of R&D support, focus on details of manufacturing.
2. Large steered cathodic arc sources to reduce droplets during depostion.
3. Accurate heating control system, the deviation is ±5℃, when the substrate surface is up to 550℃.
4. Advanced high density plasma pretreatme



Hard Film Ion Plating Machine Specifications


MATERIAL Stainless Steel (S316L)
CHAMBER SIZE Φ900*1000mm (H)
PUMP SYSTEM Rotary Piston Vacuum Pump (Mechanical)
Rotary Vane Vacuum Pump
Roots Vacuum Pump
Turbo Molecular Pump
TECHNOLOGY Ion Plating + Bias Power Bombardment
CONTROL PLC(Programmable Logic Controller)
GAS Gas Mass Flow Meters
SAFETY SYSTEM Numerous safety interlocks to protect operators and equipment
Depositon Area

Deposition area Φ680×600mm (H);

10 x Φ150mm;8 x Φ180mm;

6 x Φ210mm, for option.

HEATING Heater, up to 450℃

 Hard Coating Films Properties ( Frequently used layers)


Hard Coating Cathodic Arc Deposition System Thin Film With High Accuracy 0



Customized machine sizes are also available based on specified demanded products.


Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
