Brand Name: | ROYAL TECHNOLOGY |
Model Number: | RT-CsI950 |
MOQ: | 1 set |
Price: | negotiable |
Payment Terms: | L/C, T/T |
Supply Ability: | 10 sets/month |
The RT-CsI950 is our the 3rd upgraded generation based on CsI950 and CsI950A+ model.
The equipment is exclusively designed for CsI metallization on scintillation screens in an extremely high vacuum environment. The CsI scintillators 200~600µm in thickness ranges with high uniformity of thickness and brightness performance.
Application: for security check and inspection, high energy physics education, nuclear radiaton detection and medical imagings: chest examination, mamography, dental inter oral and panoramic.
Substrates Applied: TFT glass, Fiber Optic Plate, Amorphous-carbon plate, Aluminum plate
Benefits:
-- Compact design, more convenient for relocation;
-- More energy saving for lower production cost;
-- Qualified engineers with over 20 years technical experience in vacuum to design and build the system
Technical Advantages
1. High Efficiency
-Double-capacity for max. size substrate: 500 x400mm.
2. Repeatability & Reproducibility
-Through high precised parameter control system,
-Automated process control software and program,
-User friendly operation.
3. Reliability
-24/7 days non-stop operation;
-Inficon Film Thickness Controller to monitor the film thickness inline.
-Temperature control accuracy: ±1 ℃, multi-stage setting, automatic temperature data recording and control
-Rotary racks equipped with Servo-Motor for high accuracy and stability.
4. Safety
-High vacuum pump: Magnetic Suspension Molecular Pump, with nitrogen gas blowing device to avoid hazard material be exposed in the air;
-All electrodes are equipped with safety protection sleeves.
Technical Specifications
Description | RT-CsI950 |
|
Deposition chamber (mm)
|
φ950 x H1350 | φ800 x H800 |
Capacity | 2 | 1 |
Evaporation sources | 2 | 4 |
Dry and Dehumidity |
Iodine tungsten lamp Max. 300℃ |
Iodine tungsten lamp Max. 200℃ |
Ultimated vacuum pressure (Pa) | 8.0×10-5Pa | 5.0×10-4Pa |
Deposition Film Thickness Controller | Quartz Control x 1 |
NONE
|
Power Consumption (KW) |
Max. approx. 50 Average approx. 20 |
Max. approx. 20 Average approx. 10 |
Footprint (L*W*H) | 3000*2150*2100mm | 1800*2300*2100mm |
Operation & Control System
|
CE standard Mitsubishi PLC+ Touch Screen Operation Program with backup |
In addition to the RT-CsI950 equipment, we also provide its post-processing machines which to generate protective layer on the top of CsI film.
-- RTEP800, which is using the thermal evaporation coating technology.
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
