Aluminum Magnetron Sputtering System / High Reflection Film PVD Metalizing Machine
Royaltec manufactures the most reliable deposition systems in the PVD coating industry. The magnetron sputtering vacuum coating plant is designed with ease of maintenance in mind and the ability to handle large volume capacity. With over 90% uptime, users can focus on meeting their production demands instead of wasting time on machine maintenance. Typical Applications: Electroplate Replacement (Chrome hard coating) Automotive wheels & rims, car rear-view mirros, piston rings, car head lamps, tail lights Tableware & kitchenware: faucet Industrial Mechanical Tools Architecture Material: ceramic tile, wall glasses Sports & Entertainments: golf heads, toys Others: Lighting, eyewear, jewelry, watch, laptop, camera, mobile etc for decorative surface treatment.
The Aluminum Magnetron Sputtering System - RTSP1620-DC is designed for LED lighiting sheets coating, which can give a high reflections thin layer on sheet surface through DC Sputtering PVD process.
The system contains 2 planar Aluminum sputtering targets, with fast vacuum pumping system. The coating cycle time is only 20 mins around.
|Hight Lights of Aluminum Magnetron Sputtering System|
|1. PLC + Touch Screen Operation System||4. The design of the machine enables an easy access to the working environment for maintenance;|
|2. Flexible operation: loading/unloading||5. Planar sputtering cathode for a faster deposition.|
|3. Leybold vacuum pump packages for a stable and fast pumpdown time.||6. Glow discharging cleaning to generate high performance of coatings: bright colors, strong adhesion, uniform thickness, high density.|
Aluminum magnetron sputtering system -RTSP1620-DC Specifications
|MATERIAL||Stainless Steel (S304)|
|CHAMBER SIZE||Φ1600*2000mm (H)|
|CHAMBER TYPE||Cylinder, vertical single door|
|TECHNOLOGY||Magnetron Sputtering, DC Sputtering, Aluminum Metalizing|
|DEPOSITION SOURCES||2 SETS planar Sputtering cathodes|
|SPUTTERING TARGETS||Aluminum, Chromium, Silver etc high reflection metals|
|CLEANING||Glow discharging by bias power supply|
|CONTROL||PLC(Programmable Logic Controller) + Touch Screen|
|PUMP SYSTEM||2-stage Rotary Vane Pump|
|Rotary Vane Pump|
|Oil Diffusion Pump (or Magnetic Suspension Molecular Pump)|
|SAFETY SYSTEM||Numerous safety interlocks to protect operators and equipment|
|COOLING||Recycle Cooling Water|
|POWER MAX.||180 KW|
|AVERAGE POWER||80KW (Approx.)|
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
