PVD Ion Plating Applications:
PVD Ion Plating decorative coatings can be used not only for metal, stainless steel and glassware, but also porcelain (ceramic) material articles.
Our RTAC series machines which contain the cathodic arc evaporation sources, can coat porcelain vase and cups, dishes, etc. kitchenware, ceramic tiles, ceramic cups, plates, tableware, porcelain tiles, ceramic mosaic, floor tiles,
The machine is used to deposit TiN(gold color) ,Ti (silver color) and ZrN light/dark gold, TiAlN copper colors etc.
Since it can replace the traditional gold plating, also whole coating process is environmentally friendly, so much lower production cost, which benefit more and more customers.
PVD Ion Plating films:
It can be used to coat metal film, titanium nitride titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper.
Gold, Rose Gold, Copper, ZrN/TiN Gold, Brushed Bronze, Polished Nickel, Brushed Nickel, Polished Brass, Black etc.
Royal Technology provides the RTAC1400+ machine which is exclusively used for non-conductive substrate materials coating.
1. The multi arc vacuum coater mainly for decorative and functional film coatings.
2. Benefits: eco-environment, easy to operate, compact foot print, low cost of owner ship, fast substrate exchange.
3. Coating Colors: gold, black, brown, grey, Chrome colors etc. Gold Colors: TiN, ZrN, TiN+Au, ZrN+Au
Rose Gold Colors: TiCN, TiAlN, TiCN+Au-Cu, TiAlN+Au, Cu
Chrome colors: CrN, Ti, Cr
Gray Colors: stainless steel, stainless steel (N)
Brown Colors TiCN, TiAlCN, ZrC
Blue Color: TiO, CrO, TiALN
Black Colors: TiC, TiC+iC, TiCN, TiAlN, TiAlCN
5. Substrates: stainless sheets and tubes, metal alloys, glass, ceramic materials
6. Coatings Advantages: high shiny and bright colors, strong adhesion & excellent scratch protection, fast deposition rate, good diffraction.
RTAC1400+ machine key features
1. It's a smart and integrated design;
2. Plug-in structure, ready for using. Customer only need to connect water/gas/power
3. It is with IPC (industrial PC ) system- so remote control will be possible.
4. All commissioning/trainings are accomplished through online with prepared videos/user manual instructions.
Please contact us for more information.
