PCB (Printed Circuit Board) Gold Plating Equipment by PVD method.
The RTSP1215 machine is customized for PCB gold coatings by sputtering deposition technology.
Either you are interested in final finished products or the machine, please contact us!
General Information:
| Model | RTSP1215 | ||
| Chamber Material | SUS304 | ||
| Chamber Size | Φ1200*1500mm (H) | ||
| Deposition Technology | Magnetron sputtering | ||
| Targets | Ti,Cr,Zr, Ni, Cu, Graphite (C) etc | ||
| Vacuum Pumps | Mechanical Pump | ||
| Holding Pump | |||
| Roots Pump | |||
| Turbo Molecular pump | |||
| Gas System | MFC for plasma cleaning, reactive gas | ||
| Protective System | Multiple Self-Lock design | ||
| Operation & Control System | PLC + Touch Screen | ||
| Cooling System | Recycle Cooling water | ||
| Heating System | Heaters with PDI thermocouple | ||
| Max. Power Consumption | 130KW Approx. | ||
| Average Power Consumption | 70KW Approx. | ||
Layout:
3D design illustrations:
PCB coated samples
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
