| Chamber | Vertical Orientation, 1-door |
|---|---|
| Material | Stainless Steel 304/316 |
| Technology | DC Magnetron Sputtering Vacuum Coating, Arc Evaporation |
| Deposition Films | Al, Cu, Ag, Au, Ti, Zr, Cr Etc. |
| Applications | Car Hub, Automotive Wheels, Chrome PVD Plating |
| Deposition Sources | MF/DC Sputtering + Arc Cathodes |
|---|---|
| Deposition Films | Hard Coatings, DLC, Optical Film Coating, Decorative Coatings |
| Applications | PECVD Process, DLC Film, Diamond Like Carbon Film, Sputtering Optical Film, |
| Film Features | High Reflective, Excellent Corrosion And Wear Resistance |
| Coating Colors | Black Color And Rose Gold, Blue Colors Coating |
| Deposition Sources | Balance/Unbalanced Closed Magnetic Filed |
|---|---|
| Applications | Automotive, Semiconductor, SiC Coating, DLC Film Deposition, |
| Film Thickness | Range From 100 Nm To 12μm, Thickness Tolerance ±5% |
| Factory Location | Shanghai City, China |
| Factory Location | Shanghai City, China |
| Vacuum Technology | Cathodic Multi Arc Plating, PVD Arc Deposition, DC/MF Magnetron Sputtering |
|---|---|
| Deposition Sources | Cylinder Arc Or Circular Arc Cathodes, Planar/cylinder Sputter Source |
| Coating Films | Metal Film Plating, Titanium Nitride, Titanium Carbide, Zirconium Nitride, Chromium Nitride, TiAlN, CrC |
| Applications | Medical Instrument, Surgery Tools, Dental Tools, Heart Surgery Tools |
| Factory Location | Shanghai City, China |
| Colors | TiN Gold,Rose Gold, Copper, Blue, Light Gold, Black Etc. |
|---|---|
| PVD Coating Technoogy | Cathodic Arc Plating + MF Magnetron Sputtering |
| Name | Ceramic Coating Equipment |
| Application | Ceramic Sanitary, Ceramic Flatwares, Tablewares, |
| Feature | Semi-automatic/Automat |
| Name | Roll To Roll Continuous Magnetron Sputtering Line |
|---|---|
| Metallization Sources | DC/MF Magnetron Sputtering Deposition |
| Model | RT-R2R-SP1480 |
| Coating Thickness | Thin Film 20~40nm; Heavy Film Up To 1~2 Microns |
| Application | Carbon And Glass Fibers , Metal Coil Strips, Thickness Is Less Than 1mm |
| Chamber | Vertical Orientation, 2-door, |
|---|---|
| Material | Stainless Steel 304/316 |
| Vacuum Technology | Pvd Plating, Pvd Magnetron Sputtering, DC Sputtering |
| Deposition Sources | DC Sputtering Cathodes |
| Coating Films | Metal Film Plating, Titanium Nitride, Titanium Carbide, Zirconium Nitride, Chromium Nitride, TiAlN, CrC |
| Coating Film | Aluminum, Chrome, Titanium |
|---|---|
| Coating Products | Float Glass, Car Mirrors, Chrome Mirrors, Car Blue Mirror |
| Technology | DC Magnetron Sputtering Deposition |
| Factory Location | Shanghai City, China |
| Worldwide Service | Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America |
| Thickness | 0.5 ~ 3 Microns |
|---|---|
| Colors | TiN Gold,Rose Gold, Copper, Blue, Light Gold, Black Etc. |
| PVD Coating Technoogy | Cathodic Arc Plating + MF Magnetron Sputtering |
| Name | Ceramic Coating Equipment |
| Application | Ceramic Sanitary, Ceramic Flatwares, Tablewares, |
| Model | Batch Coating System |
|---|---|
| Coating Films | Strong Adhesion, Low Coefficient Friction, Corrosion Resistance, High Dense And Uniformity. |
| Advantages | Large Capacity, Smart Design, High Uptime And High Yield, Low Cost Of Ownership, Short Cycle Times |
| Design | Octal Chamber, 4 Sputtering Cathodes, 1 Linear Ion Source |
| Factory Location | Shanghai City, China |
