Production Line

      Advanced production machines (milling, welding, tooling, etc…) combined with standardized production

procedures and reliability testing enables Royal to produce high quality, reliable and low cost coating

equipment.



Quality, service and on-time delivery are the core principles of Royal’s business. A strategy of openly

outsourcing simple components to professional manufacturers allows us to focus attention to key parts

and components manufactured by Royal ourselves.



Mechanical Production Lines



1. Mechanical Working Plant                                                                                2. Manufacturing Machines



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 0   SHANGHAI ROYAL TECHNOLOGY INC. factory production line 1 SHANGHAI ROYAL TECHNOLOGY INC. factory production line 2



3. Assembly Working Plant



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 3 SHANGHAI ROYAL TECHNOLOGY INC. factory production line 4  SHANGHAI ROYAL TECHNOLOGY INC. factory production line 5



4. Equipment Installation and Commissioning


 SHANGHAI ROYAL TECHNOLOGY INC. factory production line 6 SHANGHAI ROYAL TECHNOLOGY INC. factory production line 7 SHANGHAI ROYAL TECHNOLOGY INC. factory production line 8



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 9

SHANGHAI ROYAL TECHNOLOGY INC. factory production line 10





4. Packaging and Delivery



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 11  SHANGHAI ROYAL TECHNOLOGY INC. factory production line 12 SHANGHAI ROYAL TECHNOLOGY INC. factory production line 13



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 14  SHANGHAI ROYAL TECHNOLOGY INC. factory production line 15





OEM/ODM

     Royal understands well that no one machine can fits all products. We listen to customers demands and provides our most suitable proposal and unique coating solutions from machine design, production till

coating recipes development. Below are some of our OEM/ODM projects.



1. Vacuum Metallizing Machine for Automotive LOGO Board,  Can coat product Max. size up to 6000mm

Model: RTEP-6638

Time: 2014 Location: China

  SHANGHAI ROYAL TECHNOLOGY INC. factory production line 0  SHANGHAI ROYAL TECHNOLOGY INC. factory production line 1



2. Vacuum Metallizing Machine for Automotive LOGO Board.

Model: RTEP-2525

Time: 2014 Location: China

     SHANGHAI ROYAL TECHNOLOGY INC. factory production line 2





3. Vacuum Metallizing Machine for Automotive LOGO Board.

Model: RTEP-3617

Time: 2015   Location: Mexico

SHANGHAI ROYAL TECHNOLOGY INC. factory production line 3



4. Vacuum Metallizing Machine for Automotive LOGO Board.

Model: RTEP-2215

Time: 2015   Location: South Korea

SHANGHAI ROYAL TECHNOLOGY INC. factory production line 4

5. RTSP1213-DC It is a sputtering system with PECVD process to deposit thin film on hydrogen fuel cell power module. Fuel Cell Vehicles is a newest technology for next generation of green cars, It is different from the primary battery such as dry cell and rechargeable battery that needs to repeat charging, but only needs Hydrogen and Oxygen reaction to generate the power for driving.

Time: 2016     Location: China

SHANGHAI ROYAL TECHNOLOGY INC. factory production line 5



6. RTAC1215-SPMF The PVD vacuum system is exclusively used for Copper Conductive Film deposition on Al2O3, AlN substrate circuit board, compared with traditional manufacturing methods: DBC, LTCC, HTCC, with PVD process, the production cost has highly reduced.

Time: 2017         Location: China

SHANGHAI ROYAL TECHNOLOGY INC. factory production line 6

7. RTEP-0913 Evaporation coating plant is applied to CsI film deposition for X-ray Imaging device. It is an advanced technique to evaporate CsI on the screen to give a high quality of imaging. With its high resolution performance, also widely used in security checking and inspection, high energy physics subjects, physics of nuclear energy areas etc.

SHANGHAI ROYAL TECHNOLOGY INC. factory production line 7

8. Optical Sputtering + DLC  Coatng Equipment

Model: Multi950

Time: 2015 Location: China, Shanghai University



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 8



9. RTEP0404 machine, with Vacuum Metalizing Deposition technology.  It is designed and developed exclusively for Fingermark imaging which is used for Police stations, criminal investigation, to provide strongly evidence for crimer's identification.The thermal evaporation machine can deposit high reflection materials: Au Gold, Ag Silver, Al Aluminum, Cu Copper, Zn Zinc etc to reflect the fingerprint marks on subjects obviously.



Time: 2016   Location: China



  SHANGHAI ROYAL TECHNOLOGY INC. factory production line 9



10. RTAS1000 machine as a laboratry application for R&D. The machine is ready for sale now.  It contains:  1 set Linear Ion source, 2 planar sputtering cathodes with MF and DC power supplies;  5 cathodic arc cathodes.



SHANGHAI ROYAL TECHNOLOGY INC. factory production line 10



More OEM and ODM projects are coming soon for promotion, we appreciate customers and our suppliers, anyone else who have  involved in these projects.

R&D

Royal has a core technological design & development team supports our customers demands.

We invest 10% of total annual sales value as the R&D fund every year, continuously efforts

brought innovation to the industry.



Our R & D team has 4 engineers who stays in the PVD vacuum coating technology more than 20 years.

We have fine collaborations with "Scientific Research and Education Institutions" like:

Shanghai University, Shanghai JiaoTong University, The University of Manchester. Which keeps us

to be the pioneer of deposition technologies in the Vacuum Coating industry.
